Monobloc pressurized superheated water generator with three flue gas passes, two of which are in the firebox, smooth tube bundles with stainless steel turbulators with a thermal power of 5000 kW, fully equipped with a 72-hour kit for automatic control and testing of the generator without the continuous supervision of a licensed operator. Maximum allowable pressure 6 bar and maximum allowable temperature 150°C. The generator has been tested and verified in the factory by Notified Body 0100 as an ASSEMBLY and certified according to European Directive 97/23/CE-PED (current 2014/68/EU). Gas-powered and complete with all accessories, it is ready for operation. The superheated water generator model PAS 500 is equipped with a 72-hour kit during the loading phase.
